MB25A REBAR BENDER • OPERATION AND PARTS MANUAL — REV. #3 (11/18/08) — PAGE 21
BENDER ASSEMBLY (continued)
NO. PART NO. PART NAME QTY. REMARKS
31 3508830 SPRING GUIDE 1
32 C5SW0601M0 WASHER, LOCK 6 1
33 7513070 ALLEN HEAD SCREW 6X35 1
34 H5HW100100 WASHER HW 10 10
35 7515050 ALLEN HEAD SCREW 10X35 10
36 3251290 TORSION COIL COLLAR 1
37 H6HW060100 WASHER, FLAT HW 6 10
38 7513030 SCREW 6X18 10
39 7200070 NEEDLE BEARING HK2526 1
40 7539010 SCREW W/ LOCK WASHER XR 4X16 2
41 6100060 RECTIFIER 1
42 H6HB051500 SCREW HB 5X15 4
43 3252220 GEAR CASE COVER 1
44 7101040 BEARING 6002Z 2
45 3510230 GEAR COLLAR No.6 1
46 6100040 MAGNET CLUTCH 1
47 7301130 THRUST NEEDLE ROLLER BEARING AS 1104 2
48 7301120 THRUST NEEDLE ROLLER BEARING AXK 1104 1
49 7550120 SCREW 5X12 3
50 H6HW050100 WASHER, FLAT 5 3
51 3601690 GEAR No. 5 1
52 7101220 BEARING 6004ZZ 1
53 7411040 SNAP RING RTW 42 1
54 3701250 KEY 1
55 3601700 GEAR No.6 1
56 7512100 BOLT HB 5X40 4
57 C5SW0501M0 WASHER, LOCK 5 4
58 7600100 WASHER, FLAT 5 4
59# 6402520 HOLDER CAP 2
60# 6402510 CARBON BRUSH 2
61# 6402450 MOTOR CASE 1
62# 6402420 STATOR 115V 1
63# 6402380 FAN GUIDE 1
64# 6402390 SCREW 5 X80 2
65# 7105020 BEARING 1
66# 6402370 INSULATOR WASHER 1
67 # 6402340 ARMATURE 115V 1
68 # 6402320 INSULATOR WASHER FOR BEARING 1
69 7000060 BEARING 6202VV 1
70 M5HB102500 ALLEN HEAD SCREW 10X25 4
MB25A — BENDER ASSEMBLY
