MB25A REBAR BENDER • OPERATION AND PARTS MANUAL — REV. #3 (11/18/08) — PAGE 19
BENDER ASSEMBLY
NO. PART NO. PART NAME QTY. REMARKS
1 M5SB122000 HEX HEAD BOLT 12 X 20 2
2 M5T4273800 WASHER A 2
3 9008090 ROLLER 625 1
3 9008080 ROLLER 622 1
3 9008070 ROLLER 619 1
3 9008060 ROLLER 616 1
3 9008050 ROLLER 613 1
3 9008040 ROLLER 610 ........................................................ 1 ......... OPTIONAL
4 9008130 COLLAR 625 1
4 9008120 COLLAR 622 1
4 9008110 COLLAR 619 1
4 3510370 COLLAR 616 1
4 3510360 COLLAR 613 1
4 3510350 COLLAR 610 1
5 7550050 ALLEN HEAD SCREW 10X25 12
6 7514000 ALLEN HEAD SCREW 8X15 4
7 9009580 TABLE 1
8 H5HB103000 ALLEN HEAD SCREW 10X30 1
9 4500380 SHOCK ABSORBER 1
10 M5B2050000 ALLEN HEAD BOLT 20X50 1
11 M5T4267800 SQUARE NUT 1
12 3502090 STOPPER PLATE 1
13 H5HB082000 HEX HEAD SCREW 8X20 4
14 3251620 STOPPER 1
15 M5K1008500 STOPPER KEY 1
16 3510260 OUTPUT SHAFT 1
17 7410130 STOP RING RTW 100 1
18 7103180 BEARING 6309DDU 1
19 7411320 SNAP RING IRTW 55 1
20 C5BTAFI385 NEEDLE BEARING HMK4530 1
21 3510270 ROLLER SHAFT 1
22 3510250 ARM 1
23 7651300 WASHER, FLAT M 14 1
24 7516200 ALLEN HEAD SCREW 14X40 1
25 7200090 NEEDLE BEARING HMK3230 1
26 7103190 BEARING 6218DDU 1
27 6601090 PIN ø13 X13 2
28 M5B6205Z00 BEARING 6205Z 1
29 3252160 FRAME 1
30 3600180 GEAR WHEEL 1
MB25A — BENDER ASSEMBLY
