engine clutch assy.
NO.
paRT NO.
paRT Name
QTy.
RemaRKS
1
1386
ENGINE, HONDA GX160UT1QX2 ....................1................5.5 HP JS36H55
1
21980
ENGINE, HONDA GX270UTQA2 ......................1................9.0 HP JS36H90
2
1475
CONNECTOR, SPLICE TAP
1
3
1488
WIRE, SAFETY SWITCH
1
4
12287
SCREW, THP 1/4- 20 X 3/4 SS
3
5
21988
LIFTING BALE ASSEMBLY J FIN
1
6
933241
WASHER, FLAT SAE 5/16 RD 9 YZ
4
8
0255
CLUTCH ASSY. 3/4" CENTRIFUGAL, 5.5 HP ...1................INCLUDES ITEMS W/@
8
0250
CLUTCH ASSY. 1" CENTRIFUGAL, 9.0 HP ......1................INCLUDES ITEMS W/#
9
0627
KEY, SQ 3/16 X 1-1/4
1
10
21994
PULLEY AK-59 X 3/4, 60-130 RPM ...................1................5.5 HP JS36H55
10
11049
PULLEY AK-49 X 3/4, 90-150 RPM ...................1................9.0 HP JS36H90
10% 21140
PULLEY AK-54 X 3/4 .........................................1................FLOAT PANS ONLY
11% 0152 3
V-BELT A28 ........................................................1................5.5 HP JS36H55/PANS
11
1243
V-BELT A27 ........................................................1................9.0 HP JS36H90
12
21970
BELT GUARD
1
13@# 0253
CLUTCH PLATE
1
14@# 1868
SCREW, SHS 3/8-24 X 3/4, NP
2
15@# 0855
SPRING, CLUTCH .156 X 5.375 X .025
1
16@# B1766
WEIGHT, AUTOMATIC CLUTCH
4
17@# 0251
DRUM, CENTRIFUGAL CLUTCH
1
18@# 0456
BEARING, SHIELDED 6007 ZZ E
1
19@ 21307
CLUTCH SPINDLE 3/4" BORE .........................1................5.5 HP JS36H55
19#
0252
CLUTCH SPINDLE 1" BORE ............................1................9.0 HP JS36H90
20
20845
SWIVEL ASSEMBLY
1
21 1834
DEFLECTOR
1
22
1273
SCREW, HHST 8-32 X 3/8
1
23
60097
LOCTITE ™ #246, BLUE
1
25
1406
PLUG, END (CLUTCH)
1
26
21915
SPACER PLATE, LIFTING BAIL
1
27
21679
SPACER, 1 X .78 X .69L
1
28
10229
SCREW, HHC 5/16-24 X 1
4
29
21678
SCREW, FHSC 5/16-24 X 1-3/4
1
30
0300 B
WASHER, FLAT SAE 5/16
1
31
LOWSPEEDKITJB LOW SPEED KIT JB FINISHER ............................. 1 ..................INCLUDES ITEMS W/ %
NOTICE
For optimum panning performance blade speed must
be changed. Use Low Speed Kit, item 31.
