jS36 SeRIeS WaLK-BeHIND TROWeL • OpeRaTION aND paRTS maNUaL — Rev. #4 (11/01/13) — page 13
engine specifications
Table 2. jS36H55 Noise and vibration emissions
model jS36H55
Guaranteed ISO 11201:2010 Based
Sound Pressure Level at Operator Station in dB(A)
92.34
Guaranteed ISO 3744:2010 Based
Sound Power Level in dB(A)
110.48
Hand-Arm Vibration Per ISO 5349-1:
2001 in m/s 2 SA(8)
Standard Handle (SXHP) 0.71
Quick Pitch TM Handle (QXHP) 0.59
Table 3. engine Specifications/Dimensions
model
Honda gX160UT2QX2
*
engine (jS36H55)
Honda gX270UT2Qa2
*
engine (jS36H90)
Less Engine
(jS36Le)
Type
Air-cooled 4 stroke, Single Cylinder,
OHV, Horizontal Shaft Gasoline Engine
Air-cooled 4 stroke, Single Cylinder,
OHV, Horizontal Shaft Gasoline Engine
Dealers and customers are
required to use engines
marked by
* in columns 1
and 2.
Bore X Stroke 68 mm x 45 mm (2.70 in. X 1.8 in.) 77 mm x 58 mm (3.0 in. X 2.3 in.)
Displacement 163 cc (9.9 cu-in.) 270 cc (16.4 cu-in.)
Max. Output 5.5 H.P. @ 3600 RPM 9.0 H.P. @ 3600 RPM
Fuel Tank Capacity
Approx. 3.6 Liters
(0.95 U.S. Gallons)
Approx. 6.0 Liters
(1.95 U.S. Gallons)
Fuel Unleaded Gasoline Unleaded Gasoline
Lube Oil Capacity 0.6 liters (0.63 qt.) 1.1 liters (1.06 qt.)
Oil Type
4-Stroke API, SF or SG
SAE 10W-30 General Use
4-Stroke API, SF or SG
SAE 10W-30 General Use
Speed Control Method Centrifugal Flyweight Type Centrifugal Flyweight Type
Cooling System Forced Air Forced Air
Starting Method Recoil Start Recoil Start
Spark Plug Type BPR6ES NGK BPR6ES NGK
Spark Plug Gap 0.70 - 0.80 mm (0.028-0.031 in.) 0.70 - 0.80 mm (0.028-0.031 in.)
Dimensions (L x W x H)
312 X 362 X 335 mm
(12.3 x 14.3 X 13.2 in.)
381 X 428 X 422 mm
(15.0 x 16.8 X 16.6 in.)
Dry Net Weight 15 Kg. (33.1 lbs.) 25 Kg. (55.1 lbs.)
NOTES:
1. Sound Pressure and Power Levels are “A” weighted Measures per ISO 226:2003 (ANSI S1.4-1981). They are measured with the operating
condition of the machine which generates the most repeatable but highest values of the sound levels. Under normal circumstances, the sound
level will vary depending on the condition of the material being worked upon.
2. The vibration level indicated is the vector sum of the RMS (Root Mean Square) Values of amplitudes on each axis, standardized to an 8 hour
exposure period, and obtained using operating condition of the machine that generates the most repeatable but highest values in accordance
with the applicable standards for the machine.
3. Per EU Directive 2002/44/EC, the daily exposure action value for whole body vibration is 0.5 m/s 2 SA(8). The daily exposure limit value is
1.15 m/s 2 SA(8).
