page 22 — J36S60 WaLK-BeHIND TROWeL • OpeRaTION aND paRTS maNUaL — Rev. #1 (01/23/13)
NeveR lift the trowel to unnecessary heights. DO NOT
stand underneath the trowel while it is being lifted. Serious
damage to the machine or personal injury could be caused
by dropping a trowel.
Starting the engine
1. Place the engine fuel valve lever (Figure 19) in the
"ON" position.
Figure 19. Engine Fuel Valve Lever (ON)
2.
Pull the
throttle lever (Figure 20) backwards and place
in the "
idle" position.
Figure 20. Throttle (Idle Position)
OFF
ON
THROTTLE
LEVER
IDLE
OperatiOn
3. Place the
centrifugal safety "STOP" switch
(Figure 21) in the "
ON" position.
Figure 21. Centrifugal Safety"Stop"
Switch (ON)
4. If starting a cold engine place the choke lever (Figure 22 )
in the "
CLOSeD" position.
Figure 22. Choke Lever (Closed)
ON
OFF
CENTRIFUGAL
SAFETY “STOP”
SWITCH
CaUTION
NEVER disable or disconnect the centrifugal "STOp"
switch. It is provided for the operator's safety and injury
may result if it is disabled, disconnected or improperly
maintained.
