J36S60 WaLK-BeHIND TROWeL • OpeRaTION aND paRTS maNUaL — Rev. #1 (01/23/13) — page 13

enGine specificatiOns

Table 3. engine Specifications/Dimensions

model

Subaru eX170Dm2230 engine

Type

Air-cooled 4 stroke, Slant Single Cylinder, OHC,

Horizontal PTO Shaft Gasoline Engine

Bore X Stroke

2.64 in. X 1.89 in. (67 mm x 48 mm)

Displacement

10.31 cu-in. (169 cc)

Max. Output

5.7 H.P. @ 4000 RPM

Fuel Tank Capacity

Approx. 0.95 U.S. Gallons (3.6 Liters)

Fuel

Unleaded Gasoline

Lube Oil Capacity

0.63 qt. (0.6 liters)

Oil Type

4-Stroke API, SF or SG

SAE 10W-30 General Use

Speed Control Method

Centrifugal Fly-weight Type

Cooling System

Forced Air

Starting Method

Recoil Start

Spark Plug Type

NKG BR6HS

Spark Plug Gap

0.028-0.031 in. (0.70 - 0.80 mm)

Dimension (L x W x H)

11.97 x 13.94 X 13.19 in. (304 X 354 X 335 mm)

Dry Net Weight

33.08 lbs (15 Kg.)
