B-46 WALK-BEHIND TROWEL • OPERATION AND PARTS MANUAL — REV. #8 (05/08/12) — PAGE 59
NO. PART NO. PART NAME QTY. REMARKS
1% * 0753 SEAL, OIL 1
2% 0131A SCREW, HHC 1/4-20 X 3/4 4
3% 12876 FLANGE, INPUT SHAFT 1
4% * 20395 O-RING, 2" 8032 N 1
6%# 20466 BEARING, CUP, TIMKEN #M11910 2
7%# 20465 BEARING, CONE, TIMKEN #LM11949 2
8% 0627 KEY, SQUARE 3/16 X 1-1/4 1
9% 1851 GEAR, WORM "B" INPUT SHAFT 1
10% 12874 CASE, WORM GEAR MACHINED 1
11% 21218 VENT, AIR 1
12 21046 GASKET/SEAL KIT..............................................1 ................. INCLUDES ITEMS W/ *
13 21047 BEARING KIT......................................................1 ................. INCLUDES ITEMS W/ #
14% 20476 SCREW, HHC 1/4-28 X 3/8 2
15% 21033 SIGHT GLASS, 3/4 M PIPE STEEL 1
16% 0121 A FITTING, PLUG 3/8 MP SQ HEAD 1
17% 1138 RING, SNAP, TRUARC 5100-112 1
18%# 20475 BEARING, CUP TIMKEN #M86610 2
19%# 20474 BEARING, CONE TIMKEN #M86647 2
20% 1140 GEAR, WORM, COMPOSITE 1
21% 20470 SHAFT, OUTPUT 1
22% 1139 KEY, WOODRUFF #810 1
23% 1238 KEY, WOODRUFF #25 1
25% * 20396 O-RING, 254 BUNA N 1
26% 12875 COVER, GEARBOX 1
27% 10235 WASHER, C/S EXT. SHKP 4
28% 20875 SCREW, FHSC 5/16-18 X 3/4 4
29% * 0254 SEAL, OIL 1
30 20407 GEARBOX ASSY. .................................................. 1 .................. INCLUDES ITEMS W/ %
31 10139 LUBE, GEARBOX OIL ISO 680, 22 OZ. (650 ML) .. 2
32 2196 SPACER, 0.5 X 0.402 X .25L 2
33 20802 RING, SNAP TRUARC 5100-37 2
34 1150 YOKE ARM 1
35 20801 PIN, YOKE 1
GEARBOX ASSY.
