B-46 WALK-BEHIND TROWEL • OPERATION AND PARTS MANUAL — REV. #8 (05/08/12) — PAGE 15
GENERAL INFORMATION
B-46 Trowel Familiarization
This walk-behind trowel is designed for the floating and
finishing of concrete slabs.
Take a walk around the trowel. Take notice of all the major
components (see Figure 3) like the engine, blades, Quick Pitch™
handle, operator presence lever, etc. Check that there is always
oil in the engine.
Read all the safety instructions carefully. Safety instructions will
be found throughout this manual and on the trowel. Keep all
safety information in good, readable condition. Operators should
be well trained on the operation and maintenance of the trowel.
Before using your trowel, test it on a flat watered down section of
finished concrete that is free of any debris and other objects.
This trial test run will increase your confidence in using the trowel
and at the same time it will familiarize you with the trowel’s
controls. In addition you will understand how the trowel handles
under actual conditions.
Engine
This trowel is available with a 9 or 11 HP HONDA gasoline
engine, or a 9 HP ROBIN gasoline engine. Refer to the engine
owner’s manual for instructions regarding the operation and
maintenance of your engine. Please contact your nearest
Multiquip Dealer for a replacement should the original manual
disappear or otherwise become unusable.
Training
For proper training, please use the “TRAINING CHECKLIST”
located in the front of this manual (Page 8). This checklist will
provide an outline for an experienced operator to provide training
to a new operator
Blades
The blades of the trowel finish the concrete as they are rotated
around the surface. This trowel comes equipped with four
combination (8 in./203mm wide) blades per rotor equally
spaced in a radial pattern and attached to vertical rotating
shaft by means of a
spider assembly.
Drive System
Power is transferred from the engine to the gearbox input shaft
via a V-belt pulley drive system. The pulley engages using a
centrifugal clutch. See Parts section of this manual.
Gearbox
The gearbox is located beneath the engine and transfers power
to the spider assembly. The gearbox controls the rotational speed
of the trowel and is equipped with two shafts (input and output).
Guard Ring
This unit is equipped with a safety guard ring. It is designed to
help protect items from coming into contact with the rotating
blades while in operation.
CAUTION CAUTION CAUTION CAUTION CAUTION
NEVER attempt to lift the trowel by yourself. ALWAYS get
the assistance of another person to help lift the trowel .
Operate the B-46 Trowel, tools and components in accordance
with the manufacturer's instructions. Use of any other tools for
stated operation is considered contrary to designated use. The
risk of such use lies entirely with the user. The manufacturer
cannot be held liable for damages as a result of misuse.
Intended Use Spider
The vertical output shaft of the gearbox connects to a cast hub
called the
spider . The spider has 4 arms that extend outward
that are used for attachment of blades or other accessories.
Remember as the gearbox output shaft rotates so does the spider
assembly.
Safety Stop Switch
In the event of a trowel runaway condition (operator releases
the handlebars), the
centrifugal safety stop switch will
stop the engine and bring the trowel to a halt.
If equipped with the optional operator presence lever , in
the event of a trowel runaway condition (operator releases
the handle), the
operator presence lever signals the safety
stop switch which will stop the engine and bring the trowel
to a halt.
Operator Presence Lever (Optional Feature)
