B-46 WALK-BEHIND TROWEL • OPERATION AND PARTS MANUAL — REV. #8 (05/08/12) — PAGE 57
BASIC UNIT ASSY.
NO. PART NO. PART NAME QTY. REMARKS
1 21973 GUARD RING 1
2 0205 SCREW, HHC 3/8-16 X 1.0 4
3 1391 SCREW, HHC 5/16-24 X 1-1/2 ZINC 4
4 10024 NUT, NYLOC 1/4-20 2
5 21929 RECEPTACLE, QUARTER TURN 1
6 21979 ACCESS PANEL, B FINISHER 1
7 26250 SCREW, HHC 1/4 - 20 X 1-3/4 2
8 21928 STUD, OVAL PHILLIPS RECESS 1
9 21930 RETAINER CLIP, QUARTER TURN STUD 1
10 21922 CLAMP, 0.625" ID PIPE 2
11 933241 WASHER, FLAT SAE 5/16 GRD 9YZ 4
12 13351 WASHER, FLAT 3/8 EXT THICK HIGH ....................... 4 ............. HONDA UNITS ONLY
