HTN/HTO- 31V • RIDE-ON POWER TROWEL — OPERATION AND PARTS MANUAL — REV. #6 (07/09/07) — PAGE 85
HTN/HTO-31V — SEAT AND FRAME ASSY.
SEAT AND FRAME ASSY.
NO
PART NO
PART NAME
QTY.
REMARKS
1
12109
FRAME, HTN SEAT W/A VAN
1
1
11829
FRAME, HTO SEAT W/A VAN
1
2
11660
PLATE, SEAT W/A HTN/HTO
1
3
21597
BUMPER, STEM ......................................... 3 ...........MAR. 27, 2006 AND ABOVE
4
21507
PLUG, PANEL 11/16 DIA.
1
5
5283
NUT, NYLOC 5/16-18
4
6
0300 B
WASHER, FLAT, 5/16 SAE
4
7
19468
GROMMET, MINOR Z-4004 ......................... 2 ...........MAR. 27, 2006 AND ABOVE
8
21936
CONNECTOR, BODY 2-PIN ......................... 1 ...........MAR. 27, 2006 AND ABOVE
9
21938
WIRE ASSY., KILL SWITCH 37" ................. 1 ...........MAR. 27, 2006 AND ABOVE
10
21861
SEAT, ADJUSTABLE W/O ARMS ................ 1 ...........MAR. 27, 2006 AND ABOVE, SEE NOTE
11
8081
PIN, CLEVIS 1/2X2 3/4
2
12
0183
PIN, COTTER 1/8X1 1/4
2
13
5218
SCREW, HHC 1/2-13X1 1/2
8
14
5054A
WASHER, LOCK, 1/2 MED.
8
15
4684
WASHER, FLAT, 5/8 PLD ............................. 1 ...........MAR. 26, 2006 AND BELOW
16
11593
SPRING, SEAT ............................................ 1 ...........MAR. 26, 2006 AND BELOW
17
8156
SCREW, HHC 3/8-16X2 1/2 ......................... 1 ...........MAR. 26, 2006 AND BELOW
18
4001
WASHER, FLAT, 3/8 USS PLD .................... 1 ...........MAR. 26, 2006 AND BELOW
19
10133
NUT, NYLOC 3/8-16 ..................................... 1 ...........MAR. 26, 2006 AND BELOW
20
12005
SWITCH, KILL ............................................. 1 ...........MAR. 26, 2006 AND BELOW
21
12307
BULB, INDICATOR LIGHT
3
22
12305
PLUG INDICATOR LIGHT
3
23
21870
SEAT KILL SWITCH .................................... 1 ...........MAR. 26, 2006 AND ABOVE
24
20989
SEAT, ADJUSTABLE .................................... 1 ...........MAR. 26, 2006 AND BELOW,
....................................................................................SEE NOTE
NOTE
WHEN OLD STYLE SEAT, PARTS ORDER STOCK HAS BEEN DEPLETED (ITEM 24). NEW STYLE
SEAT MUST BE ORDERED (ITEM 10).
