wrs5200dfpu hydraulic rOller screed • parts manual — rev. #0 (08/18/14) — page 55
nO. part nO. part name Qty. remarKs
1 0400 B SCREW HHC 5/16-18 X 1/2" 1
2 69300001 CAP, RADIATOR 1
5 11534 NUT, ''U'' TyPE, 1/4-20 16
7 12318 SCREW, HHC 1/2-13 X 2-3/4" 2
13 20742 ISOLATOR, RB2 RING/BUSHING 2
14 20743 WASHER, ISO SNUB 2
16 21231 ISOLATOR, PLATE-STUD 5/16" 1
17 21739 BRACkET, RADIATOR BOTTLE 1
18 21740 BOTTLE, RADIATOR 1
19 21781 NUT, FLANGED 3/8-16 SERRATED PLTD 4
23 23729 RADIATOR 1
24 68901053 HOSE, RADIATOR, LOWER 1
25 68901054 HOSE, RADIATOR, UPPER 1
26 88800049 CLAMPS 4
28 32380 SCREW, HHFS 3/8-16 X 1-1/2" ZN 4
29 36720 SCREW, HHFS 5/16-18 X 3/4" GRD 5 2
30 36900 MOUNT W/A, VRADIATOR 1
42 49048 SCREW, HHFS 1/4-20 X 3/4" GRD 5 7
43 49071 NUT, FLANGED 5/16-18 SERRATED PLTD 1
44 60146 HOSE, RADIATOR OVERFLOW 5/16" ID 1
45 30119 SCREW, HHFS 1/4-20 X 3/4" GRD 5 2
RaDiaToR assy.
