wrs5200dfpu hydraulic rOller screed • parts manual — rev. #0 (08/18/14) — page 37
lPg fUel Hose assy.
nO.
part nO.
part name
Qty.
remarKs
3
9091
SCREW, HHFS 5/16-18 X 1" GRD 5
2
5
15538
CLAMP, HOSE WORM #6
4
6
36995
HOSE ASSy., 1/4"ID LPG X 26", 1/4MP ENDS
1
9
21781
NUT, FLANGED 3/8-16 SERRATED PLTD
4
16
26132
FITTING, STR 1/4MP X 1/4MP
1
17
26798
FITTING, 90° 6MJ-6FJ
1
20
30021
FITTING, STR 6MJ X 4MBPT
1
21
30025
HOSE, HOT WATER, .375 DIA. 200 PSI, 52" ........................... 5 ........... 1PC = 1 FT
22
30025
HOSE, HOT WATER, .375 DIA. 200 PSI, 27" ........................... 3 ........... 1PC = 1 FT
24
35358
PALNUT, U, 5/16-18 X .05/.20 PANEL
2
25
36994
HOSE ASM,1/4"ID LPG X 18.50",1/4MP X-6FJ 90°
1
27
42185
VALVE, SOLENOID, W/FILTER, 12VDC,1/4MP X 1/4FP
1
28
42200
VALVE, PRESSURE RELIEF-LP
1
32
46034
SCREW, HHFS 3/8-16 X 2.00"
4
34
46106
FITTING, COUPLING 1/4FP X 1/4FP
1
36
46169
BRkT, LP FILTER
1
37
46170
BULkHEAD, LPG 1/4NPT
1
39
60004
HOSE, FUEL .1875 DIA. LOW PERM 50 PSI, 38.5" ................ 4 ........... 1PC = 1 FT
40
EG65146923
VAPORIZER ASSy.
1
41 EG28345850 JOINT
1
42 EG28346620 JOINT
2
