wrs5200dfpu hydraulic rOller screed • parts manual — rev. #0 (08/18/14) — page 47
ConTRol valve assy.
nO.
part nO.
part name
Qty.
remarKs
1
36518
VALVE, 3-WAy
1
2
49070
NUT, 1/4" FLANGE HEAD
3
3
5277
SCREW, BHC 1/4-20 X 3/8" NyL PATCH, NP
3
4
46041
HOSE ASM,1/2" ID X 31.0" -10FJ
1
5
16336
FITTING, 45° 10MJ-10MO
1
6
3322
FITTING, 90° 10MJ-10MO
2
7
46039
HOSE ASM,1/2" ID X 26.0" -10FJ ENDS
1
9
16598
FITTING, NUT 10 BLkHD JAM
2
10
16597
FITTING, STR 10MJ-1/2MP BLkHD
1
11
16564
FITTING, QD PARkER H4-62 FEM 1/2FP
1
12
16569
COVER, 1/2 FEMALE
1
13
21096
FITTING, STR 10MJ-12MO
1
14
36520
FITTING, 90° 8MJ-12MO
1
15
16565
FITTING,QD PARkER H4-63 MALE 1/2FP
1
16
16568
COVER, 1/2 MALE
1
17
36950
HOSE ASM,1/2"ID X 15.0" -10FJ X -10FJ 90°
1
18
60125-22
PROTECTOR, SPIRAL HOSE, HI-TEMP, 12" L ....................... 1 ........... 1PC = 1 FT
19
49070
NUT, 1/4" FLANGE HEAD
1
