wrs5200dfpu hydraulic rOller screed • parts manual — rev. #0 (08/18/14) — page 35
fUel Hose assy.
nO.
part nO.
part name
Qty.
remarKs
2
4692
TERMINAL, BULLET, .156 MALE, 14-16 GA
1
3
EG60152030
FUEL PUMP ASSy.
1
4
11534
NUT, "U" TyPE, 1/4-20
2
6
17206
FITTING, 90° 5BARB - 1/4MP
1
7
19317
FITTING, BRASS BUSHING 1/4FP X 3/8MP
1
8
19473
CLAMP, HOSE WORM #2
8
9
21781
NUT, FLANGED 3/8-16 SERRATED PLTD
10
10
23506
CANISTER, CARBON, 800CC
1
11
23507
GROMMET, ROLL OVER VALVE
1
12
23508
VALVE, ROLL OVER
1
13
23514
CAP, RATCHET W/GAUGE "GASOLINE" (10.5")
1
14
46199
ADAPTER, HOSE, SS
1
15
23794
CLAMP, HOSE WORM #64, 3-9/16" TO 4-1/2"
2
22
30026
HOSE, CARB VAPOR, 12" ....................................................... 1 ........... 1PC=1FT
29
46000
TANk W/A, VTFUEL-10 GAL
1
31
46033
SCREW, HHFS 3/8-16 X 3/4"
2
33
46072
GAUGE,LOW FUEL SENSOR W/PLUG
1
35
60004
HOSE 8-1/2" ............................................................................. 1 ........... 1PC = 1FT
38
49048
SCREW, HHFS 1/4-20 X 3/4" GRD 5
2
39
60004
HOSE, FUEL .1875 DIA. LOW PERM 50 PSI, 15" ................... 2 ........... 1PC = 1 FT
40
60028
HOSE, FUEL .312 DIA. LOW PERM 50 PSI, 6" ....................... 1 ........... 1PC = 1 FT
41
60028
HOSE, FUEL .312 DIA. LOW PERM 50 PSI, 2" ....................... 1 ........... 1PC = 1 FT
42
1258143012
FUEL FILTER
1
43
60028
HOSE, FUEL .312 DIA. LOW PERM 50 PSI, 17" ..................... 2 ........... 1PC = 1 FT
44
60028
HOSE, FUEL .312 DIA. LOW PERM 50 PSI, 23" ..................... 2 ........... 1PC = 1 FT
46
911329
FITTING, PLUG 3/8 MP MAGNET ........................................... 1 ........... 1PC = 1 FT
47
36920-4
FUEL PUMP
1
