PAGE 24 — C-30HDN PUMP — OPERATION AND PARTS MANUAL — REV. #11 (03/29/12)
C-30HDN PUMP — INSPECTION
Figure 10. Engine Oil Dipstick
e
p
y
T
li
O
.
3
e
l
b
a
T
n
o
s
a
e
S
e
r
u
t
a
r
e
p
m
e
T
e
p
y
T
li
O
r
e
m
m
u
S
r
e
h
g
i
H
r
o
C
°
5
2
0
3
-
W
0
1
E
A
S
ll
a
F
/
g
n
i
r
p
S
C
°
0
1
~
C
°
5
2
0
2
/
0
3
-
W
0
1
E
A
S
r
e
t
n
i
W
r
e
w
o
L
r
o
C
°
0
0
1
-
W
0
1
E
A
S
3. Check the engine oil level as shown on the dipstick.
4. If the engine oil level is low, add oil through the engine oil filler
hole (Figure 12) with the recommended oil type (Table 3).
Maximum oil capacity is 3-3/8 quarts (3.2 liters).
DIPSTICK
OIL FILLER
HOLE
Figure 11. Engine Oil Filler Hole
Engine Oil Check
1. To check the engine oil level, place the pump on secure
level ground with the engine stopped.
2. Remove the dipstick from its holder (Figure 10) and wipe it
clean.
Reference manufacturer engine
manual for specific servicing
instructions.
NOTE
CAUTION - General Saftey Guidelines
ALWAYS wear approved
eye
and
hearing
protection before operating the pump .
NEVER operate the pumps's engine with the
engine hood removed. The possibility exists
of
hands
,
long hair
, and
clothing
becoming entangled with the V-belt, causing
injury and bodily harm.
NEVER place hands or feet inside the
hopper
. ALWAYS make
while the engine is running. ALWAYS shut-down the engine
before performing any kind of maintenance service on the
pump.
NEVER operate the pump in a confined
area or enclosed area structure that does
not provide ample
free flow of air
.
Before Starting
1. Read safety instructions at the beginning of
this manual.
2. Removing any dirt and dust that might have accumulated
around the engine cooling air inlet, fuel injection system.
3. Check the air filter for dirt and dust. If air filter is dirty, replace
air filter with a new one as required.
4. Check fuel injection system for external dirt and dust. Clean
with dry compressed air.
5. Check fastening nuts and bolts for tightness.
6. Connect Battery
7. Make sure hopper is free of dirt and foreign debris (large
objects over 2-inches)
8. Make sure radiator is filled with proper amount of anti-freeze
water solution (50/50).
9. Make sure all hose lines are in good condition and are working
properly.
