QP2TH TRASH PUMP • OPERATION AND PARTS MANUAL — REV. #5 (01/29/14) — PAGE 33
PUMP ASSEMBLY
NO.
PART NO.
PART NAME
QTY.
REMARKS
38
0151191257
STUD BOLT, (DRAIN COVER HANDLE)
4
M12 X 57 X15 X 22
39#
0520030310
KEY, 4.7 X21 MM ...................................................1............REPLACES P/N 0520030413
40
43592012400011 IMPELLER WASHER, DIA. 35 X 9 MM T4.5
1
41
0204490060
U-NUT, WEAR PLATE M6
3
42
0205490080
NUT, ENGINE M8
4
43
0205490100
NUT, CUSHION RUBBER M10
8
44
0205490100
NUT, PUMP M10
2
45
0451290100
SPRING WASHER, PUMP M10
2
46
0401650080
WASHER, ENGINE M8
4
47
0457290080
SPRING WASHER, (VOLUTE CASING)M8
2
48
0451290080
SPRING WASHER, (DRAIN COVER SET M8
4
49
0451290100
SPRING WASHER, (CUSHION RUBBER) M10 8
50
0451290080
SPRING WASHER, (ENGINE) M8
4
51#
0458220080
SPRING WASHER, (IMPELLER), M8 ...................1............REPLACES P/N 0451290080
52
0451290080
SPRING WASHER, (CASING COVER ) M8
4
53 0742214050 STRAINER
1
54 1889108050 CAP
1
55 0481310700 O-RING
1
56
1889250770
OVERFLOW SUPPRESSOR
1
57
GX160K1QX2
ENGINE, HONDA 5.5 HP ......................................1............S/N 2TH-3428 AND BELOW
57
GX160U1QX2
ENGINE, HONDA 5.5 HP ......................................1............S/N 2TH-3429 TO 2TH-13438
57
GX160UT2QX2 ENGINE, HONDA 5.5 HP ......................................1............S/N 2TH-13439 AND ABOVE
