QP2TH TRASH PUMP • OPERATION AND PARTS MANUAL — REV. #5 (01/29/14) — PAGE 31
NO. PART NO. PART NAME QTY. REMARKS
1 1889100011 CASING 1
2 1889100020 CASING COVER 1
3 18890001600014 SUCTION COVER 1
4 1889100171 DRAIN COVER 1
5 19920002200014 DRAIN COVER HANDLE 4
6 1889040031ASSY IMPELLER KIT .......................................................1............INCLUDES ITEMS W/ #
7 1889000132 VOLUTE CASING 1
8 1889100741 SUCTION PLATE 1
9 1247100250 DRAIN COVER SET HANDLE 2
10 1889330410 SUCTION PLATE PACKING 1
11 1992250700 WEAR PLATE 1
12 0191190525 BOLT(CASING COVER), 5/16-24 UNF 4
13 07904320200014 NIPPLE, NPS2" X NPT2" 2
14 1889350351 CHECK VALVE 1
15 0105090840 BOLT (ENGINE), M8 X40 4
16 1211390610 CASING COVER PACKING, OIL SHEET 1
17 0481571950 O’RING (DRAIN COVER) 1
18 0489402910 O’RING (CASING), 4 X 291 MM 1
19 1889214010P002 BASE, SS400 1
20 0481310550 O-RING (NIPPLE) 2
21# 0482200180 O-RING“ (MECHANICAL SEAL SLEEVE) 2
22 18892140200014 ENGINE BASE, SS400 1
23 0631211159 FLOODING CAP, PF1-1/2" 1
24 0631211159 DRAIN CAP, PF1-1/2" 1
25 0803442930 MECHANICAL SEAL 1
26 0811345443 MECHANICAL SEAL SLEEVE, DIA. 25MM 1
27 0852833020 ADJUST LINER DIA. 20 X 30 MM TO.3 1
27-1 0852853020 ADJUST LINER DIA. 20 X 30 MM T0.5 1
28# 0191190544 BOLT(IMPELLER), 5/16-24 UNF X 1-3/4 ...............1............REPLACES P/N 0191190525
29 0131190820 SCREW (VOLUTE CASING) M8 X 20 ...................2............REPLACES P/N 0141090820QP2
30 0141090825 SCREW (DRAIN COVER SET HANDLE) M8 X 25 4
31 0131191270 CAP SCREW (CASING), M12 X 70 1
32 0131191235 CAP SCREW (CASING), M12 X 35 4
33 0105091035 BOLT (PUMP), M10 X 35 2
34 0459220120 SEAL WASHER (CASING) M12 1
35 0723302040 CUSHION RUBBER, 40 X 20 M10 4
36 0181090820 BOLT SET W/SPRING WASHER M8 X 20 2
(SUCTION PLATE)
37 0181090825 BOLT SET WITH SPRING WASHER M8 X 25 4
PUMP ASSEMBLY
NOTICE
Item 21, O-ring, is included in impeller kit, item 6. When
ordered as part of the kit, quantity of o-ring is one.
Replacement of impeller requires two o-rings, so it is
necessary to order one additional o-ring.
