PAGE 12 — QP2TH TRASH PUMP • OPERATION AND PARTS MANUAL — REV. #5 (01/29/14)
SPECIFICATIONS (ENGINE)
Table 2. Specifications (Engines)
Engine
Model
HONDA GX160K1QX2/
GX160U1QX2/GX160UT2QX2
Type
Air-cooled 4 stroke, Single
Cylinder, OHV,
Horizontal Shaft Gasoline
Engine
Bore x Stroke
2.7 in. x 1.8 in.
(68 mm x 45 mm)
Displacement 163 cc (9.9 cu-in)
Max Output 4.8 H.P./3,600 R.P.M.
Fuel Tank Capacity
Approx.0.82 U.S. Gallons
(3.1liters)
Fuel Unleaded Automobile Gasoline
Lube Oil Capacity 0.61 quarts (0.58 liters)
Speed Control Method Centrifugal Fly-weight Type
Starting Method Recoil Start
Dimension
(L x W x H) 12.0 x 14.4 x 13.2 in.
(304 x 362 x 335 mm)
Dry Net Weight 33.1 lbs (15 Kg.)
Figure 2. QP2TH Performance Curve
0
10
20
30
40
50
60
70
80
90
100
110
0 50 100 150 200
Suction Line : 2 inch Discharge Line : 2 inch
U.S GALLONS
PER MINUTE
LITERS
PER MINUTE 200 400 600 100 300 500 700 0
TOTAL HEAD
METERS FT
5
10
15
20
25
30
3.3 FT 23.3 FT 16.7 FT 10 FT
