MVH408GH PLATE COMPACTOR • OPERATION AND PARTS MANUAL — REV. #0 (03/25/14)— PAGE 75
NO. PART NO. PART NAME QTY. REMARKS
1 16854ZH8000 RUBBER, SUPPORT (107MM) 1
3 16955ZE1010 JOINT, FUEL TANK 1
4 17510Z5T000ZA TANK CP, FUEL/BLACK 1
12 91353671003 O-RING 14MM ..................................................1................REPLACES 91353671004
14 91424Z5T003 TUBE, FUEL, 4.5X235 (FKM) 1
15 9405008000 FLANGE NUT M8 2
16 950024080008 CLAMP, TUBE (D8) 1
17 957010802500 FLANGE BOLT 8X25 2
18 17620Z4H900 FUEL TANK CAP CP. ........................................1................INCLUDES ITEM W/ #
19# 17631Z0T801 PACKING, FUEL FILLER CAP 1
22 17672Z4H000 FILTER, FUEL 1
HONDA GX390UT2SMXC — FUEL TANK ASSY.
