MVH408GH PLATE COMPACTOR • OPERATION AND PARTS MANUAL — REV. #0 (03/25/14)— PAGE 57
NO. PART NO. PART NAME QTY. REMARKS
1 11300Z8W800 COVER ASSY., CRANKCASE/S-TYPE ............1................INCLUDES ITEMS W/@
2 11381Z5T000 PACKING, CRANKCASE COVER 1
3 15600Z0T820 CAP ASSY., OIL FILLER ..................................1................INCLUDES ITEM W/ $
4 15600Z1C000 CAP ASSY., OIL FILLER ..................................1................INCLUDES ITEM W/ $
5$ 15625Z0T800 PACKING, OIL FILLER CAP 2
6@ 16510ZE3000 GOVERNOR ASSY. ..........................................1................INCLUDES ITEMS W/ #
7@ 16531Z0A000 SLIDER, GOVERNOR 1
8@ 90602ZE1000 CLIP, GOVERNOR HOLDER 1
9 90701HC4000 PIN, DOWEL 2
10@ 91201Z1C003 OIL SEAL 1
11@ 58176 WASHER, FLAT 6MM .......................................1................REPLACES 9410106800
12 957010804000 BOLT, FLANGE 8X40 7
13@ 961006202000 BEARING, RADIAL BALL 6202 1
14@ 961006207000 BEARING, RADIAL BALL 6207 1
15@# 16511ZE8000 WEIGHT, GOVERNOR 3
16@# 16512ZE3000 HOLDER, GOVERNOR WEIGHT 1
17@# 16513ZE2000 PIN, GOVERNOR WEIGHT 3
HONDA GX390UT2SMXC — CRANKCASE COVER ASSY.
