MVH408GH PLATE COMPACTOR • OPERATION AND PARTS MANUAL — REV. #0 (03/25/14)— PAGE 41
BASE AND ENGINE ASSY.
NO. PART NO. PART NAME QTY. REMARKS
1 468121260 BASE L100 1
2 912239016 ENGINE ASSY., GX390UT2SMXC 1
3 0105051045 BOLT 10X45 T ...................................................4................REPLACES 001221045
4 030210250 WASHER, LOCK M10 4
5 031110160 WASHER, FLAT M10 4
7 468352240 BELT COVER, IN 1
8 009110071 SOCKET HEAD BOLT 10X25 T 4
11 468352120 DUST COVER 1
12 092006010 FLAT HEAD SCREW 6X10 6
13 468467050 PLATE, BELT COVER 1
14 952408810 SPACER 25X31.8X10 1
15 456343340 CLUTCH ASSY. 1
16 951400110 KEY 7X7X35 1
17 952406050 SPECIAL WASHER 1
18 011208030 BOLT 8X30 T .....................................................1................REPLACES 001220830
19 030208200 WASHER, LOCK M8 1
22 070200453 V-BELT B-45 1
24 954407310 UNION, DRAIN 1
25 0091720000 HOSE CLAMP 2
26 0211140020 GASKET 2
27 0401140030 PLUG 1
28 465459390 DRAIN HOSE 1
29 464457380 DRAIN JOINT 1
30 014208020 BOLT 8X20 T .....................................................1................REPLACES 001220820
31 030208200 WASHER, LOCK M8 1
33 467121100 BELT COVER (OUT) 1
34 467351800 DUST SPONGE (OUT) 2
35 001521054 SOCKET HEAD BOLT 10X70 T 4
37 468352140 FRONT BUMPER 1
38 001521435 SOCKET HEAD BOLT 14X35 T 2
39 030214350 WASHER, LOCK M14 2
40 468121230 FRONT COVER 1
