MVH408GH PLATE COMPACTOR • OPERATION AND PARTS MANUAL — REV. #0 (03/25/14)— PAGE 45
ELECTRIC DEVICE ASSY.
NO. PART NO. PART NAME QTY. REMARKS
18 468218970 REAR COVER 1
19 011006010 BOLT 6X10 T .....................................................8................REPLACES 001220610
20 030206150 WASHER, LOCK M6 8
21 009120413 SUNK HEAD BOLT 6X15 6
22 030206150 WASHER, LOCK M6 6
23 020106050 NUT M6 .............................................................6................REPLACES 020306050
25 467466950 RUBBER COVER, REAR 1
26 009110062 SOCKET HEAD SCREW 6X20 3
27 022710607 NYLON NUT M6 3
75 515010070 GROMMET 1
90 009110072 PAN HEAD SCREW 5X35 2
91 952407930 COLLAR 6X10X13.5 2
92 58151 WASHER, FLAT M5 ..........................................2................REPLACES 031105080
93 030205130 WASHER, LOCK M5 2
94 022710506 NYLON NUT M5 2
96 955010311 TACHO/HOUR METER 1
100 955010307 CLIP BELT 1
101 955010308 CURL CORD 1
102 959026828 RUBBER TUBE L=850 1
103 955407970 WIRING FIXED BASE 3
104 454010020 CLAMP TC-100 3
105 2067550101 CLAMP COMPL 1
106 955301010 STOP SWITCH,ENGINE 1
107 468467570 READ CORD 1
108 467466980 LEAD WIRE (SW-GROUND) 1
110 020108060 NUT M8 .............................................................1................REPLACES 020308060
111 959021812 SPIRAL TUBE 6D-800L 1
112 515450380 WIRE HARNESS/MRH-600, 700 1
113 955407970 WIRING FIXED BASE 3
114 454010020 CLAMP 3
