MVC88VTH/VTHW pLaTe COMpaCTOR • OpeRaTiOn and paRTs ManuaL — ReV. #2 (12/09/13) — page 33
VIbRATOR ASSY.
nO. paRT nO. paRT naMe qTy. ReMaRks
1 953405270 PLUG 1/4X14 X13L 1
2 953405260 PACKING 1/4" 1
3 416218390 ECCENTRIC ROTATOR 1
4 040406211 BEARING 6211 2
5 416338909 CASE COVER (R) 1
6 416338919 CASE COVER (L) 1
7 416349930 BELT COVER GUARD 1
8 060203030 OIL SEAL 1
9 050101000 O-RING 2
10 014208020 BOLT 8X20 8
11 030208200 WASHER, LOCK M8 8
12 416464470 PULLEY, VIBRATOR ASSY. 1
13 951405240 KEY 7X7X19 1
14 952404250 WASHER 11X40X4 1
15 0105091025 BOLT 10X25 1
16 030210250 WASHER, LOCK M10 1
