MVC88VTH/VTHW pLaTe COMpaCTOR • OpeRaTiOn and paRTs ManuaL — ReV. #2 (12/09/13) — page 11
SpECIfICATIONS
Table 1. MVC88VTH/VTHW One-Way
plate Compactor specifications
Centrifugal Force
3,372 lbs. (1,530 kg)
Vibration Frequency
6,000 vpm (60 Hz)
Traveling Speed
82 ft/min (25 m/min)
Plate Size (L x W)
19.7 x 20.7 in (.500 x .525 mm)
Max. Area of Compaction (no extensions)
8,100 sq. ft./hr (752 sq. m/hr)
Operating Weight MVC88VTGH
Operating Weight MVC88VTHW
207 lbs. (95 kg.)
229 lbs. (104 kg.)
Water Tank Capacity
13.7 qt (13.0 liters)
Anti-Vibration Handle
Yes
Lubricating Oil in Vibration Case
6.7 fl. oz. (200 cc)
Table 2. engine specifications
Engine Make
HONDA
Engine Model
GX160UT2QMX2
Engine Type
Air-cooled 4 stroke, Single Cylinder, OHV,
Horizontal Shaft Gasoline Engine
Cylinder Bore X Stroke
2.7 in. x 1.8 in. (68 mm x 45 mm)
Displacement
163 cc (9.9 cu-in)
Maximum Ouput
4.8 HP (3.6 kW) @ 3600 RPM
Fuel Tank Capacity
Approx. .825 U.S. gallons (3.1 liters)
Fuel Type
Unleaded 86 Octane or Higher
Oil Capacity
.61 qts (0.58 liters)
Air Cleaner
Dual Element
Starting Method
Recoil Start
Dry Net Weight Recoil/Electric
33 lbs (15 Kg.)
Dimensions (L x W x H)
12.2 x 14.3 x 13.6 in (312 x 362 x 346 mm)
