MTX-60 RAMMER • OPERATION AND PARTS MANUAL — REV. #6 (08/23/11) — PAGE 53
HONDA GX100KRBF ENGINE — CARBURETOR ASSY. (S/N T-3424 AND ABOVE)
CARBURETOR ASSY. (S/N T-3424 AND ABOVE)
NO. PART NO. PART NAME QTY. REMARKS
1 * 16010Z0DV02 GASKET, METERING DIAPHRAGM 1
2 * 16011Z0DV02 GASKET, PUMP 1
3 * 16013Z4ES32 DIAPHRAGM ASSY, METERING 1
4 * 16014Z0DV02 DIAPHRAGM, PUMP 1
5 * 16018ZM3004 SCREEN, INLET 1
6 * 16019ZM3004 VALVE, INLET NEEDLE 1
7 * 16022ZM3014 PIN, METERING LEVER 1
8 * 16023Z0DV02 LEVER, METERING 1
9 * 16030ZM3004 SPRING, PUMP 1
10 * 16040Z4E802 COVER, PUMP 1
11 * 16041Z0DV02 SCREW 1
12 * 16042Z0DV02 SPRING 1
14 * 16044Z4E802 SCREW 1
15 * 16045Z0DV02 STOP, THROTTLE 1
16 * 16046Z0DV73 LEVER, THROTTLE 1
17 * 16048Z0DV02 SPACER, THROTTLE LEVER 1
18 * 16049Z4ES12 SCREW, IDLE ADJUSTING 1
19 * 16050Z0DV02 SPRING 1
20 * 16051Z0DV02 VALVE, THROTTLE 1
21 * 16052Z0DV02 SHAFT, THROTTLE 1
22 * 16053Z0DV02 CLIP, THROTTLE SHAFT 1
23 * 16054Z0DV02 SCREW, VALVE 2
24 * 16055Z0DV02 SCREW ASSY 1
25 * 16056Z0DV02 SPRING 1
26 * 16057Z0DV02 BALL 1
27 * 16058Z0DV02 SHAFT ASSY, CHOKE 1
28 * 16059Z0DV03 VALVE, CHOKE 1
29 * 16060Z0DV02 SCREW 1
30 * 16061Z0DV02 SEAL, DUST 2
31 16100Z4ES43 CARBURETOR ASSY (W/PRIMER) .................................. 1 .........INCLUDES ITEMS W/ *
32 16211Z0DV00 INSULATOR, CARBURETOR 1
33 16212Z0DV00 PACKING, INSULATOR 1
34 16213Z4ES10 INSULATOR B, CARBURETOR 1
35 16214Z0DV00 PACKING B, INSULATOR 1
36 16215Z0DV00 PLATE, INSULATOR 1
37 16221Z0DV00 PACKING, CARBURETOR 2
38 * 16552896650 COLLAR, LEVER 1
39 950014527050 HOSE, FUEL 4.5 X 270 1
40 950024085008 CLAMP, TUBE 2
41 * 99101Z0D048 JET (#48) 1
41 * 99101Z0D050 JET (#50) 1
41 * 99101Z0D052 JET (#52) 1
41 * 99101Z0D054 JET (#54) 1
42 950033602620 TUBE, VINYL. 11 X 13 X 260 1
44 * 16017Z4ES32 BODY ASSY, AIRPURGE 1
45 * 16026Z4ES32 COVER, PRIMER PUMP 1
46 * 16032Z4ES32 PUMP, PRIMER 1
47 * 16055Z4ES32 SCREW ASSY 4
