MTX-60 RAMMER • OPERATION AND PARTS MANUAL — REV. #6 (08/23/11) — PAGE 43

HONDA GX100KRBF ENGINE — PISTON/CONN. ROD ASSY.

PISTON AND CONNECTING ROD ASSY.

NO.

PART NO.

PART NAME

QTY.

REMARKS

1

13010Z0D003 RING SET, PISTON

1

2

13101Z0D000 PISTON

1

3

13111ZE0000 PISTON PIN

1

4

13200Z0D000 CONNECTING ROD ASSY. ........................ 1 ............INCLUDES ITEM W/

*

4

13200Z0D305 CONNECTING ROD ASSY. ........................ 1 ............UNDERSIZE, INCLUDES ITEM W/

*

5

*

90001ZM7000 CONNECTING ROD BOLT

2

6

90551ZE0000 CLIP, PISTON PIN 13MM

2
