MT55F RAMMER — OPERATION AND PARTS MANUAL — REV. #5 (01/06/12) — PAGE 59
NO PART NO PART NAME QTY. REMARKS
B 2846233200 CARBURETOR ASSY. ............................................... 1 ............... INCLUDES ITEMS W/ #
2# 2846253908 LEVER SUB ASSY. THROTTLE 1
3# 2846256008 COLLAR 1
4# 2846231608 SPRING, THROTTLE 1
5# 2516255908 BUSH 1
6# 2846253308 SHAFT, THRO 1
7# 2846253508 THROTTLE VALVE 1
8# 2846245508 SCREW 2
9# 2846252908 LEVER CHOKE 1
10# 2846252308 SHAFT CHOKE 1
11# 2846252908 VALVE CHOKE 1
12# 2846240108 MAIN JET #68 1
13# 2846242008 SLOW JET 1
15# 2516244908 SRING 2
16# 2776258108 SCREW ADJUST 2
17# 2846251508 PIN, FLOAT LEVER 1
18# 2846250508 FLOAT ASSY. 1
19# 2796250008 VALVE NEEDLE 1
20# 2846254008 GASKET CHAMBER 1
21# 2846255208 CHAMBER ASSY. FLOAT 1
22# 2516266108 DRAIN SCREW 1
23# 2846233508 SCREW 1
24# 2516235008 GASKET 1
25# 2846246508 NUT 2
26# 2846246008 SPRING WASHER 2
27# 2846245008 O-RING 1
28# 2846245108 O-RING 1
29# 2846256308 PLATE 2
30# 2846245608 SCREW 1
31# 2846246008 JET 1
32# 2846243008 COLLAR 1
33# 2516256508 RUBBER PIPE 1
40# 2844550103 BUSH, THRO 1
ROBIN EH-092D ENGINE — CARBURETOR ASSY.
