MT55F RAMMER — OPERATION AND PARTS MANUAL — REV. #5 (01/06/12) — PAGE 31
NO. PART NO. PART NAME QTY. REMARKS
93 351420390 PISTON PIN 1
94 080100120 STOP RING R-12 2
95 351324120 PISTON ROD 1
96 362455680 PISTON END 1
97 020116130 NUT M16, P1.5 1
98 351434200 STOPPER, UPPER 1
99 351434211 STOPPER, LOWERD:30 1
100 362452830 MAIN SPRING, A,B 2
101 362341640 SPRING CYLINDER 1
102 362214820 FOOT PLATE 1
103 050100750 O-RING G-75 1
104 050930850 O-RING JASO3085 1
105 001521020 SOCKET HEAD BOLT 10X20 T 4
106 001521035 SOCKET HEAD BOLT 10X35 T 4
107 351209590 GUIDE CYLINDER 1
108 050100950 O-RING G-95 2
109 351316870 BELLOWS CLAMP, W/B40L,N,SV 2
110 351433250 BAND GUIDE/BELLOWS 2
111 001210840 BOLT 8X40 H 2
112 020308060 NUT M8 2
113 050100800 O-RING G-80 1
114 002211040 BOLT 10X40 H,SW 4
115 351109020 PROTECTION SLEEVE 1
118 959010150 LEVEL GAUGE, PLUG TYPE 1
119 953404670 COPPER PACKING 17X25.5X1 1
120 353332870 BELLOWS (OR) 1
GUIDE CYLINDER ASSY.
