MT55F RAMMER — OPERATION AND PARTS MANUAL — REV. #5 (01/06/12) — PAGE 35
NO. PART NO. PART NAME QTY. REMARKS
A 305910031 F.TANK AY 2L (GRAY) ............................... 1 ............... INCLUDES ITEMS W/ *
B 362910060 THROTTLE LEVER ASSY. ........................ 1 ............... INCLUDES ITEMS W/ #
51 # 362341550 THROTTLE BODY 1
52 # 362455610 THROTTLE GEAR 1
53 # 362455620 SLIDER 1
54 # 362455630 THROTTLE LEVER 1
55 * # 050100450 O-RING G-45 1
56 # 050200100 O-RING P-10 1
57 # 031110160 SCREW M10 3
58 # 033910070 CONICAL SPRING WASHER 2
59 # 096206006 SOCKET HEAD SCREW 6X6 1
60 # 022131008 CAP NUT M10 1
61 # 020410060 NUT M10,H=6 1
62 # 096208020 SOCKET HEAD SCREW 8X20 1
63 # 020408050 NUT M8, H=5 2
64 # 956100040 THROTTLE WIRE 620-710 1
65 001220620 BOLT 6X20 T 2
66 030206150 WASHER, M6 2
67 022130605 CAP NUT, M6 2
68 351325590 SHOCK ABSORBER 100D-45B 2
69-1 033121009 SOCKET HEAD BOLT 10x20 T 4
69-2 033121009 TOOTHED LOCK WASHER B M10 4
70 002211020 BOLT 10X20 H, SW 4
71 939010210 STOPPER RUBBER EH1002 ..................... 1 ............... S/N N2299 AND BELOW
71 939010270 STOPPER RUBBER EH (70) ..................... 1 ............... S/N N2300 AND ABOVE
72 030208200 WASHER, M8 1
73 020308060 NUT M8 1
74 * 361910021 TANK CAP CP (ORANGE) ......................... 1 ............... INCLUDES ITEM W/$
74-1 * $ 353449010 STRAP, FUEL TANK 1
75 * 351437785 HOLDER, COCK 1
76 * 954406020 PACKING, FUEL TANK 1
77 * 954406010 STRAINER (#110) 1
78 001220830 BOLT 8X30 T 2
79 030208200 WASHER M8 2
80 022710809 NYLON NUT M8 2
81 952401450 WASHER 8.5X22X3 2
83 362116890 FUEL TANK 2L (GRAY) 1
TANK AND HANDLE ASSY.
