MT55F RAMMER — OPERATION AND PARTS MANUAL — REV. #5 (01/06/12) — PAGE 27
NO. PART NO. PART NAME QTY. REMARKS
1 362116510 CRANK CASE 1
2 362341650 CRANK GEAR 1300-59Z 1
3 040006305 BEARING 6305 1
4 040006203 BEARING 6203 1
5 952401450 WASHER 8.5X22X3 1
6 001220825 BOLT 8X25 T 1
7 030208200 SW M8 1
8 362455660 BEARING COVER 1
9 050100350 O-RING G-35 1
10 002210620 BOLT 6X20 H, SW 2
11 303010060 CONNECTING ROD 1
12 040006304 BEARING 6304 1
13 080100520 STOP RING R-52 1
14 952400130 WASHER 9304 1
15 001220825 BOLT 8X25 T 1
16 030208200 SW M8 1
17 303010084 PINION 1
18 040006007 BEARING 6007 1
19 041006007 BEARING 6007Z 1
20 351437750 SPACER 35.4-42.7-11 1
21 080200350 STOP RING S-35 1
22 351421900 SPACER, CLUTCH DRUM 1
23 060404010 OIL SEAL TC-40528 1
24 050300900 O-RING S-90 1
25 362454440 CLUTCH ASSY./CE120M 0.5C .................... 1 ............ INCLUDES ITEMS W/ *
25-1 * 943020020 CLUTCH SHOE C812 4
25-2 * 943050050 CLUTCH BOSS C812 1
25-3 * 943060090 CLUTCH GUIDE (A) 1
25-4 * 943060020 CLUTCH GUIDE/B 1
25-5 943030021 CLUTCH SPRING 2
26 0053204201 WOODRUFF KEY 1
27 301010210 LOCK WASHER, CLUTCH 1
28 0173120010 LOCK NUT 1
29 362341610 PACKING, FRONT COVER 1
30 002210620 BOLT 6X20 H,SW 9
31 2741500123 ADAPTER, FLANGE 1
32 0011408400 BOLT & WASHER ASSY. 4
33 0021808000 NUT 4
34 0032008000 SPRING WASHER 4
35 0031108000 WASHER 4
36 0310060020 DOWEL PIN 2
37 959006120 CLIP (TCP2-10509B) 1
38 362341620 OIL GAUGE PROTECTOR 1
39 362341630 LINK PROTECTOR 1
40 002400820 BOLT 8X20 SW, PW 4
CRANKCASE AND ENGINE ASSY.
