MTS Dual-Point Shear Fixture-1000 kN User Manual
Dual-point shear fixture, 1000 kn, Mts fundamental
Copyright information
© 2010 MTS Systems Corporation. All rights reserved.
Trademark information
MTS is a registered trademark and MTS Fundamental is a
trademark of MTS Systems Corporation within the United
States. These trademarks may be protected in other countries.
Contact information
MTS Systems Corporation
http://www.mts.com/en/Global/index.asp
ISO 9001 Certified QMS
Specifications
Model
F-JJ106A1 -01
-02
-03
Maximum Load (kN)
1000
Weight (kg)
5.1
Height (mm)
270
Width (mm)
130
Depth (mm)
130
Specimen
Metal
Specimen Diameter (mm)
Φ10
Φ15
Φ20
Specimen Length (mm)
150
Temperature Range (°C)
0 to +50
Saline Tolerant
No
Immersion Proof
No
Dual-Point Shear Fixture, 1000 kN
http://support.mts.com
MTS Fundamental
™
