Model 685.53 Grip Control Module
20
Adjusting the Rate Control
Operation
Adjusting the Rate Control
The Rate control may be adjusted at any time. If the grips act too fast to suit your
personal preference, turn the Rate control clockwise to slow the speed of grip
action. Turning the Rate control counterclockwise speeds up grip action.
Turning the Rate control fully clockwise stops the flow of fluid to the grips. If
the grips do not operate, check to be sure that the Rate control has not been
turned fully clockwise.
Adjustment of rate is a matter of personal preference. It should be based on the
desired speed of grip action during the gripping and ungripping processes. (The
speed of grip action is dependent both on the adjustment of the rate control and
the particular grips being used.)
When first operating the grips, use a slower speed (lower rate setting). Then
increase the operating speed to your satisfaction.
