Electromechanical, vertical, 2.4 kn (550 lb) – MTS Bionix EnviroBath User Manual
Page 25
Bionix® EnviroBath™ Chamber
Installation
25
Bionix EnviroBath 6 Chamber Common Mounting Configurations
Note
Adapters (for example “B”, “C”, “D”) referenced in the following
illustration are detailed in
Electromechanical,
vertical, 2.4 kN (550 lb)
M6 AT
LOWER
ADAPTER
CL
M6X1 ON
UNIVERSAL
CL
MOUNT-UPPER
COUPLING ASSY
4X M5X.8 ON A 1.688BC
"B", "C", "D"
MALE
MALE "D"
ACCESSORY MOUNTING-
ACCESSORY
1.970
.750
18.500
5.100
