Page 23
23
ITEM
NO.
DESCRIPTION
PART OR
IDENTIFYING NO.
QTY.
REQ.
1
CHASSIS/MK-VTS/50
PG-10128
1
2
WASHER/FLAT 1/2" GB STL
500160
2
3
PIVOT PLATE ASSEMBLY/MK-VTS/50
PG-10126
1
4
HANDLE WELDMENT / MK-VTS/50
PG-10131
1
5
WHEEL LEG
06-500-25
2
6
SCR/CAP HEX 1/2"-13 X 1.25"
5002200
2
7
1/2"-13 NYLOX NUT
05-78108
2
8
WASHER/FLAT 5/8" GB
5001070
2
9
AXLE WELDMENT / MK-VTS/50
06-500-30
1
10
COLLAR, 1.13" OD X .625" ID X .50" WIDE
CP-10100
1
11
ADJUSTMENT T-BAR WELDMENT
06-550-4
1
12
8" REAR WHEEL, 8" OD X 5/8" HUB X 1-7/8" WIDE
06-500-29
2
13
ADJUSTMENT SHAFT WELDMENT/MK-VTS/50
PG-10127
1
14
COLLAR, 1-1/2" X 7/8" ID X .55" WIDE
CP-10099
1
15
AXLE ADJUSTMENT KNOB /MK-VTS/50
CP-10098
1
16
PIVOT BRKT COVER
06-550
2
17
FRONT COUNTER WEIGHT/MK-VTS/50
PA-10607
1
18
SHOCK ABSORBER/60 DURO NEOPRENE/MK-VTS/50
06-505-102
4
19
MOTOR/ELECTRIC 1HP, 60HZ
06-550-10
1
20
WASHER/LOCK 3/8"
5001150
9
21
SCR/CAP HEX 3/16" - 16 X 2.00" G5 STL
5002000
4
22
SCR/CAP HEX 0.375 - 16 X 1.000 G5 STL
800771
1
23
CUTTING HEAD / MK-VTS/50
PA-10622
1
24
FLANGE BEARING / 2 BOLT
06-5280-6
1
25
SCR/CAP HEX .375 -16 X 1.250" G5 STL
5007680
2
26
NUT, HEX, SFL, 5/16 - 18
5000810
8
27
TOOL HOLDER WELDMENT / MK-VTS/50
PG-10130
1
28
SCR/CAP HEX .375 - 16 X .75" GS STL
5001190
2
29
WASHER/LOCK 1/4"
500930
7
30
.375 - 16 X 1.00" THUMB SCREW FLT POINT
800766
2
32
SCR/CAP HEX .250 - 20 X .625" G5 STL
5001730
8
33
HANDLE/GRIP 4.5 LONG X 7/8: ID
P004024
2
34
PANEL/ELEC. CONTROL - MK-VTS/50 120V/60HZ
P004942
1
35
PLATE, SWITCH COVER PLATE / MK-VTS/50
PA-10544
1
36
ECCENTRIC / MK-VTS/50
06-550-101
1
37
PLATE/SERIAL-NUMBER USF/SAWTEC
05-55501
1
38
DECAL/WARING-EYE AND EAR PROTECTION
05-65643
1
39
DECAL / 120 VOLT
05-65647
1
40
DECAL/ DO NOT USE EQUIPMENT TO FILTER
P004118
1
41
DECAL/MADE IN USA
P001420
2
42
NUT, HEX, CL, 3/8 - 16
153522
2
MK-VTS/50 FLOOR SCRAPER
PARTS LIST
