silica dust Warning

Grinding/cutting/drilling of masonry, concrete, metal and other materials can generate dust, mists and fumes containing

chemicals known to cause serious fatal injury or illness, such as respiratory disease, cancer, birth defects or other repro-

ductive harm. If you are familiar with the risks associated with the particular material being cut, review the material safety

data sheet and/or consult your employer, the material manufacturer/supplier, governmental agencies such as OSHA and

NIOSH and other sources of hazardous materials. California and some other authorities, for instance, have published lists

of substances known to cause cancer, reproductive toxicity, or other harmful effects. Control dust, mist and fumes at the

source where possible. In this regard use good work practices and follow the recommendations of the manufacturer/sup-

plier, OSHA/NIOSH, and occupational and trade associations. When the hazards from inhalation of dust, mists and fumes

cannot be eliminated, the operator and any bystanders should always wear a respirator approved by OSHA/MSHA for the

material being cut.

cup Wheel

1/16" - 1/8"

7" Dust Shroud

InstructIon sheet

Shim is for use with a DeWalt or Jepson grinder, or as cup wheel is worn,

it may be used to achieve distance if needed.

If necessary place large washer(s) on cup adapter nut, so cup wheel

extends 1/6" to 1/8" beyond shroud.

Shim

Cup Adapter Nut

Large Washer

Hex Nut

1. Lift nose of shroud.

2. Place against wall

and grind.

hinged nose Instructions

1. Screw cup nut on

grinder arbor shaft.

4. Screw hex nut onto

cup nut.

2. Place washer on top

of cup nut.

3. Place cup wheel

on washer.

cup nut adapter For use With arbor cup Wheels
