5" dust shroud, Silica dust warning – MK Diamond IXL 5" Dust Shroud User Manual

Page 2

Silica Dust Warning

Grinding/cutting/drilling of masonry, concrete, metal and other materials can generate dust, mists and fumes containing

chemicals known to cause serious fatal injury or illness, such as respiratory disease, cancer, birth defects or other repro-

ductive harm. If you are familiar with the risks associated with the particular material being cut, review the material safety

data sheet and/or consult your employer, the material manufacturer/supplier, governmental agencies such as OSHA and

NIOSH and other sources of hazardous materials. California and some other authorities, for instance, have published lists

of substances known to cause cancer, reproductive toxicity, or other harmful effects. Control dust, mist and fumes at the

source where possible. In this regard use good work practices and follow the recommendations of the manufacturer/sup-

plier, OSHA/NIOSH, and occupational and trade associations. When the hazards from inhalation of dust, mists and fumes

cannot be eliminated, the operator and any bystanders should always wear a respirator approved by OSHA/MSHA for the

material being cut.

Cup Wheel

1/16" - 1/8"

Shim

Cup Adapter Nut

Large Washer

Hex Nut

5-inch Shroud Part List
Item Description

Part #

Clamp, Hose, 1-15/16 to 2-1/4

162816

Assembly, Cup Nut

167149

Shroud, 5"

170791

Adapter Bushing, 5" Shroud

170792

NOTE: Use washer(s) to achieve proper distance if

needed.

As cup wheel is worn use additional

washer to achieve distance needed.

5" Dust Shroud

INSTRUCTION SHEET
