PSP-8

SPAN-LINE 36A

© Metal Sales Manufacturing Corporation/ Subject to change without notice/ Effective Date 9/11

800.406.7387 (Corporate Office) • www.metalsales.us.com

sPan-line 36a

o

uTside

C

orner

d

eTail

i

nside

C

orner

d

eTail

Span-Line 36A Outside Corner

Tape Sealant

Span-Line 36A Panel

1

/

4

"-14 x

7

/

8

" Stitch (1'-0" o.c.)

Span-Line 36A Jamb

#12-14 x 1

1

/

2

" SD (1'-0" o.c.)

Span-Line 36A Inside Corner

Tape Sealant

Span-Line 36A Panel

1

/

4

"-14 x

7

/

8

" Stitch (1'-0" o.c.)

Span-Line 36A Jamb

#12-14 x 1

1

/

2

" SD (1'-0" o.c.)
