Soffit-panel – Metal Sales Soffit User Manual
Page 9
PSO-9
SOFFIT-PANEL
© Metal Sales Manufacturing Corporation/ Subject to change without notice/ Effective Date 9/11
800.406.7387 (Corporate Office) • www.metalsales.us.com
soffiT-Panel
Pancake Head Driller (1'-0" o.c.)
Soffit Panel
Pop-Rivet (1'-0" o.c.)
Soffit Panel Miter Trim
J
amb
D
eTail
s
offiT
To
w
all
D
eTail
Pancake Head Driller (1'-0" o.c.)
Soffit Panel
Pop-Rivet (1'-0" o.c.)
Soffit Panel Jamb
