Soffit-panel – Metal Sales Soffit User Manual
Page 8
PSO-8
SOFFIT-PANEL
© Metal Sales Manufacturing Corporation/ Subject to change without notice/ Effective Date 9/11
800.406.7387 (Corporate Office) • www.metalsales.us.com
soffiT-Panel
Pancake Head Driller (1'-0" o.c.)
Tape Sealant
1.25" Sill to Soffit
Soffit Panel
Pop-Rivet (1'-0" o.c.)
Soffit Panel
s
ill
To
s
offiT
D
eTail
Pancake Head Driller (1'-0" o.c.)
1.5" Base
Soffit Panel
b
ase
D
eTail
