CLASSIC RIB
®
CLASSIC RIB FASTENING PATTERN
d
esign
/ i
nsTallaTion
C
onsideraTions
(
ConT
.)
Classic Rib Panel
1
/
4
"14 x
7
/
8
" Stitch Screw (1'-0" o.c.)
Anti-Siphon Groove
Classic Rib Fastening Pattern - Interior
Classic Rib Fastening Pattern - Ends
