PCR-13
CLASSIC RIB ®
© Metal Sales Manufacturing Corporation/ Subject to change without notice/ Effective Date 9/11
800.406.7387 (Corporate Office) • www.metalsales.us.com
ClassiC rib
r
idge
d
eTail
g
ravel
s
ToP
d
eTail
3:12 Slope
Minimum
#12-14 x 1 1 /
2
" SD (see below)
Tape Sealant
Classic Rib Outside Closure
Classic Rib Panel
1 /
4
"14 x 7 /
8
" Stitch Screw (every rib)
Universal Ridge
#12-14 x 1 1 /
2
" SD (see below)
Tape Sealant
Tape Sealant
Classic Rib Outside Closure
Classic Rib Panel
1 /
4
"14 x 7 /
8
" Stitch Screw (every rib)
Fastener (by others)
Gravel Stop
3:12 Slope
Minimum
Classic Rib Fastening Pattern
#12-14 x 1 1 /
2
" SD
1 /
4
"14 x 7 /
8
" Stitch (1'-0" o.c.)
Classic Rib Fastening Pattern
#12-14 x 1 1 /
2
" SD
1 /
4
"14 x 7 /
8
" Stitch (1'-0" o.c.)
