Memmert ONE 7 - 45 Oilbath (Generation 2003) - Manual (Page 17)

EXCELLENT page 17
4.3.8.2 Selection of temperature monitor (waterbaths only)
Setting:
2
or 3.1
Rotate the push/turn control until flashes.
With the SET key depressed it is possibile to select the temperature monitor as
adjustable temperature limiter (TWB) Protection Class 2 to DIN 12880, or as
adjustable temperature monitor (TWW) Protection Class 3.1 (see also sections
4.3.6 and 7)
°C
°C
5 Programming example of a programme sequence
monitor temperature
setpoint temperature
monitor temperature
setpoint temperature
Class 2 Class 3.1
1. Setpoint temperature setting
Rotate the push/turn control until the
°C symbol flashes. With the SET key
depressed, use the push/turn control to set the temperature setpoint to f.ex.
90.0
°C
°C
2. Delayed switch-on setting
Rotate the push/turn control until the (delay) and the symbol flashes. With
the SET key depressed, use the push/turn control to set the time f.ex. 6.00.
°C
3. Hold time setting
Rotate the push/turn control until the (hold) and the symbol flashes. With
the SET key depressed, use the push/turn control to set the time f.ex. 4.00.
°C
4. Setpoint-dependent waiting time setting
Rotate the push/turn control until
flashes. With the SET key depressed, use
the push/turn control to set on.
°C
°C
5. Switch on the circulating pump (WPE 45 only)
Rotate the push/turn control until the symbol flashes. With the SET key
depressed, use the push/turn control to set on.
°C
6. Monitor temperature setting
Rotate the push/turn control until the monitor temperature display flashes. With
the SET key depressed, use the push/turn control to set the monitor temperature
to f.ex. 91.5°C.
°C
°C
*
t
*
t
