8
0 1 MEDIUM 2
1 1 LOWEST
A. Auto mode
When dipswitches #9
are both set at OFF, the fixture works in Auto mode. Please
check above DIPSWITCH SETUP for reference.
B. Sound Active mode
When dipswitch #9 is ON and dipswitch #10 is OFF the fixture works in Sound active mode.
Please check above DIPSWITCH SETUP for reference.
C. MASTER/SLAVE Mode
Master: set the dipswitch #10 of one LED PAR Light to OFF; the other dip switches 1-9
control the speed of the programs. Master mode has three working ways: auto with fade,
auto without fade and sound. Please refer to DIPSWITCH SETUP above.
Slave: set all the dip switch #1 & #10 to ON, #2-9 dip switches to OFF
D. DMX mode
When dipswitch #10 is set at ON, the fixture works in DMX mode. By various
combining the Dipswitches #1 to #9 you can set the address ranging from 1 to 512.
At this moment, the fixtures can be controlled by DMX controller or another fixture
that has been designated as Auto or Sound Active mode with 5 channels receiving
the data controlling the Red, Green, Blue, brightness and strobe rate output of the
fixture respectively.
Note: the address encoded by combining dipswitches #1 to #9 function as initial
channel address.
