7
2.3 Operation Instructions
DIP SWITCH SETUP 1=ON 0=OFF X= ON or OFF
Dip switch
Function
#
1
#2 #3 #4 #5 #6 #7 #8 #9 #10
DMX Mode Dip 1~9 for DMX address setup 1
Master X X X X X X X X X 0
Slave X X X X X X X X X 1
Stand
Alone
AUTO
with
fade
Dip 1~3 for
selection of 7
static colors
Setting
flashing
or not:
ON for
flashing
Dip 5 & 6
for
selection of
4 speeds
Dip7 for
setting
7-color
changing
or static
colors
1 0 0
AUTO
0 0 0
Sound X X X X X 1 0
NOTES:
DIP10 for setting Stand Alone or DMX/Slave mode.
DIP 9 for setting AUTO or SOUND in Stand Alone mode.
DIP 8 for setting fade effect in AUTO mode.
DIP 7 for setting static color mode or color changing mode in AUTO.
In static color mode, one can select single color using dip 1~3. Also, one can set DIP 4 to
“ON” position for flash effect and DIP 5~6 for desired flashing speed.
In color chasing mode, set DIP 5~6 for desired color changing speed.
Static Color
#1 #2 #3 Static Color
0 0 0 RED
1 0 0 GREEN
0 1 0 BLUE
1 1 0 YELLOW
0 0 1 ORANGE
1 0 1 PURPLE
0 1 1 CYAN
1 1 1 WHITE
Flashing Speed
#5 #6 SPEED
0 0 HIGHEST
1 0 MEDIUM
1
