INSTALLATION
Important Note: Do not connect USB devices to the hub until you are
instructed to do so in step 4 of this user guide.
1. Plug the AC adapter into a wall outlet, or surge suppressor. Plug the
DC connector into the DC Power Jack found on the rear of the hub
2. Plug the flat end (USB A connector) of the provided USB device cable
into the downstream port of your computer, or downstream port of
another hub, then plug the other end (USB mini B connector) of the
device cable into the upstream port on the rear of the hub.
Important Note: The hub must be connected to a USB 2.0 compliant host
in order to function in Hi-Speed mode (480Mbps data
rate). If the hub is connected to a USB 1.1 compliant
host, it will operate only in Low Speed or Full Speed
mode (1.5 Mbps/12 Mbps).
3. Windows will now detect your hub and install the required driver
support. (The Windows “Install New Hardware Wizard” may prompt
you to provide your Windows Installation CD to complete the driver
installation process).
