Overview – Belkin F5U237EA User Manual
Page 8
4
OVERVIEW
Technical Specifications
Upstream Ports
(1)
Downstream Ports
(7)
Per-port Voltage
DC +5V
Per Port Current
500mA (max)
Power Mode
Self-Powered
Operating Temperature
5ºC ~ 40ºC
Storage Temperature
-20ºC ~ 60ºs
Enclosure ABS
Power Supply
Output:
DC 6V, 4A
Plug Size:
3.5mm (outer) 1.0mm (center)
Plug Polarity:
Center Positive
Main Power LED Color Definitions:
Off
Not Operational
Red
Operational
Port Status LED Color Definitions:
Off
Over Current Condition
Green
Fully Operational
P74387ea_F5U237ea_uk 09-09-2003 10:07 Page 4
