MAG.LAYERS

MMD-04BZ-SERIES-X2

■

■

■

P

P

P

A

A

A

C

C

C

K

K

K

A

A

A

G

G

G

I

I

I

N

N

N

G

G

G

Peel-off Force

165° TO 180°

TOP COVER TAPE

BASE TAPE

The force for peeling off cover tape is 10 to 70 grams in the arrow direction.

Dimension (Unit: mm)

C

D

A

E

B

F

TYPE

SIZE

A

B

W

P

T

MMD

04BZ

4.4

4.9

12

8

2.3

TYPE

A

B

C

D

E

F

330 mm

330±2

100±1

20±0.5

13 ±1.0

16 ±0.5

20 ±2
