Mag Layers USA MLV-YT10NSERIES-M1 User Manual
Page 2
MAG.LAYERS
MLV-YT10NSERIES-M1
■
■
■
P
P
P
R
R
R
O
O
O
D
D
D
U
U
U
C
C
C
T
T
T
D
D
D
I
I
I
M
M
M
E
E
E
N
N
N
S
S
S
I
I
I
O
O
O
N
N
N
NOTE：Dimensions in mm
PRODUCT NO.
A
B
C
D
MLV-YT10NSERIES-M1
2.5 ± 0.2 2.0
± 0.2
1.0 Max
0.6 ± 0.2
■
E
E
E
L
L
L
E
E
E
C
C
C
T
T
T
R
R
R
I
I
I
C
C
C
A
A
A
L
L
L
R
R
R
E
E
E
Q
Q
Q
U
U
U
I
I
I
R
R
R
E
E
E
M
M
M
E
E
E
N
N
N
T
T
T
S
S
S
R
dc
(mΩ)
PART NUMBER
INDUCTANCE
Lo(μH)±30%
@0A
Typ.
Max
HEAT RATING
CURRENT(Idc)
DC AMPS
1
SATURATION
CURRENT(Isat)
DC AMPS
2
MLV-YT10NR24N-M1
0.24 14
17 4.0
5.0
MLV-YT10NR47N-M1
0.47 25
33 3.0
4.5
MLV-YT10NR50N-M1
0.50 29
37 2.85
4.0
MLV-YT10NR68N-M1
0.68 40
50 2.7
3.7
MLV-YT10N1R0N-M1
1.0 56
66 2.5
2.9
MLV-YT10N1R5N-M1
1.5 88
98 1.9
2.7
MLV-YT10N2R2N-M1
2.2 120
132 1.5
2.1
TEST FREQUENCY:1MHz,0.25V
TESTING INSTRUMENT L :Agilent4285A, CH3302/G LCR METER
CH1320,CH1320S BIAS CURRENT SOURCE
R
dc
:CH11025,GOM802 MICRO OHMMETE
NOTES:
1.DC current (I
dc
) that will cause an approximate △T of 40℃
2.DC current (I
sat
) that will cause Lo to drop approximately 30%
3.All test data is referenced to 25℃ ambient
4.Operating Temperature Range -40℃ to +85℃
5. Withstand voltage : 25V DC
