TABLE 1
Inductance Percent Test Resistance Rated DC Current
L( μH) Tolerance Frequency RDC( Ω) Max.
0.9 N 100kHz/0.25V 7.80m R90
1.4 N 100kHz/0.25V 9.10m 1R4
2.0 N 100kHz/0.25V 11.7m 2R0
3.6 N 100kHz/0.25V 19.5m 3R6
4.7 N 100kHz/0.25V 23.4m 4R7
6.8 N 100kHz/0.25V 32.5m 6R8
10 M,N 100kHz/0.25V 44.2m 100
15 M,N 100kHz/0.25V 65.0m 150
22 M,N 100kHz/0.25V 85.8m 220
33 M,N 100kHz/0.25V 0.130 330
47 M,N 100kHz/0.25V 0.195 470
68 M,N 100kHz/0.25V 0.299 680
100 M,N 100kHz/0.25V 0.377 101
※ □ specify the inductance tolerance,M( ±20%),N(±30%)
Based on temperature rise (△T： 40℃ Max.)
MNR-8040-SERIES Page-2/8
Marking
MAGLAYERS
PT/NO.
MNR-8040-220□
MNR-8040-R90□
MNR-8040-100□
MNR-8040-150□
MNR-8040-1R4□
MNR-8040-2R0□
IDC(A)
MNR-8040-3R6□
MNR-8040-4R7□
MNR-8040-6R8□
MNR-8040-330□
7.80
7.00
6.30
4.90
4.10
3.70
3.10
2.40
2.20
1.70
1.40
※IDC : Based on inductance change (△L/Lo：drop 30% Max.) @Ambient Temperature : 25℃ and
MNR-8040-470□
MNR-8040-101□
MNR-8040-680□ 1.10
1.00
