TABLE 1
Inductance Percent L Test SRF(MHz) Resistance
L( μH) Tolerance Frequency Typ. RDC( Ω)±30% IDC1(A) IDC2(A)
0.9 N 100KHz/0.25V 90 13m 6.60 4.60 R90
2.2 N 100KHz/0.25V 68 20m 4.20 3.70 2R2
4.7 M,N 100KHz/0.25V 39 31m 2.70 3.00 4R7
10 M,N 100KHz/0.25V 20 65m 1.90 1.90 100
22 M,N 100KHz/0.25V 12 0.135 1.30 1.40 220
33 M,N 100KHz/0.25V 10 0.22 1.10 1.10 330
47 M,N 100KHz/0.25V 8.0 0.30 0.95 0.92 470
68 M,N 100KHz/0.25V 5.0 0.42 0.76 0.77 680
100 M,N 100KHz/0.25V 3.0 0.60 0.62 0.66 101
220 M,N 100KHz/0.25V 1.0 1.30 0.45 0.50 221
※ □ specify the inductance tolerance,M( ±20%),N(±30%)
※ IDC1： Based on inductance change (△L/Lo：drop 30% Max.) @ ambient temp. 25℃
IDC2： Based on temperature rise (△T： 40℃ Typ.)
Rated DC Current： The less value whith is IDC1 or IDC2.
MNR-6028-SERIES Page-2/8
